The Cisco WAP125 Kenya is a Wireless-AC Dual Band Desktop Access Point with PoE provide a simple, cost-effective and secure wireless networking to your employees for best experience to stay connected anywhere in the office.

Description

Cisco WAP125 Wireless-AC Dual Band Access Point Kenya

The Cisco WAP125 Kenya is a Wireless-AC Dual Band Desktop Access Point with PoE provide a simple, cost-effective and secure wireless networking to your employees for best experience to stay connected anywhere in the office. This flexible solution lets you connect dozens of employees, and can scale to accommodate additional users and changing business needs. The Cisco WiFi Kenya access point uses concurrent dual-band radio for improved coverage on mobile devices. A Gigabit Ethernet LAN interface with PoE supports flexible installation and can reduce cabling and wiring costs. Intelligent Quality-of-Service (QoS) features let you prioritize bandwidth-sensitive traffic for Voice over IP (VoIP) and video applications.

To provide highly secure guest WiFi access to visitors and other users, the Cisco WAP125 access point supports a captive portal with multiple authentication options and the ability to configure rights, roles, and bandwidth. A customized guest login page lets you present a welcome message and access details, and reinforces your brand with company logos. Cisco WAP125 access point also offers support for 3rd party cloud managed guest WiFi services allowing you to control internet access for guests and give your customers a better guest WiFi experience.

The Cisco WAP125 Kenya access point is easy to set up and use, with intuitive and mobile friendly wizard-based configuration to get you up and running in minutes. An attractive, compact design with integrated stand allows the access point to be placed on a desk or other flat surface.

To enhance reliability and safeguard sensitive business information, this Cisco WiFi Kenya supports both Wi-Fi Protected Access (WPA) Personal and Enterprise, encoding all your wireless transmissions with powerful encryption. In addition, 802.1X RADIUS authentication helps keep unauthorized users out. Also, Cisco WAP125 access point is integrated with Cisco Umbrella to protect employee and guest WiFi against web threats such as malware, ransomware and more.

Features

  • The single radio supports both 5 GHz and 2.4 GHz, with speeds up to 867 Mbps for increased capacity and coverage
  • The Gigabit Ethernet LAN interface can enable a high-speed uplink to the wired network
  • Robust security, including WPA2, 802.1X with RADIUS secure authentication, and rogue access point detection, helps protect sensitive business information
  • A captive portal supports secure, customized guest access with multiple rights and roles
  • Simple installation and an intuitive web-based configuration wizard enable fast, simple deployment and setup in minutes
  • Support for PoE makes installation easy without expensive additional wiring
  • Support Plug and Play feature for mass deployments, when using FindIT network management platform
  • Sleek design with multiple internal antennas and integrated stand
  • Intelligent QoS prioritizes network traffic to help keep critical network applications running at top performance
  • Workgroup Bridge mode lets you expand your network by wirelessly connecting to a second Et

Specifications

Standards IEEE 802.11ac, 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X (Security Authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460)
Cabling type Category 5e or better
Antennas Internal antennas optimized for installation on desktop
Led indicators 1 multifunction LED
Operating system Linux
Physical Interfaces
Ports 10/100/1000 Ethernet, with support for 802.3af /at PoE, power port for AC adapter (included)
Power supply External 12V/1A DC power jack (Energy Star 2.0 compliant with Efficiency Level 6) and 802.3af/at PoE
Buttons Reset button, power on/off push button
Lock slot Slot for Kensington lock
LEDs 1 LED
Physical Specifications
Physical dimensions
(W x D x H)
4.85 x 4.85 x 1.25 in. (123 x 123 x 31 mm)
Weight 0.67 lb (303 g)
Network Capabilities
VLAN support Yes
Number of VLANs 1 management VLAN plus 8 VLANs for SSIDs
802.1X supplicant Yes
SSID-to-VLAN mapping Yes
Auto-channel selection Yes
Spanning tree Yes
Load balancing Yes
IPv6 Yes

IPv6 host support

IPv6 RADIUS, syslog, Network Time Protocol (NTP)

Layer 2 802.1Q-based VLANs, 8 active VLANs plus 1 management VLAN
Security
WPA/WPA2 Yes, including enterprise authentication
Access control Yes, management Access Control List (ACL) plus MAC ACL
Secure management HTTPS
SSID broadcast Yes
Rogue access point detection Yes
Mounting and Physical Security
Mounting options Desktop
Physical security lock Kensington lock slot
Quality of Service
QoS Wi-Fi Multimedia and Traffic Specification (WMM TSPEC), client QoS
Performance
Wireless throughput Up to 867-Mbps data rate (real-world throughput will vary)
Recommended user support Up to 64 connective users, 10 active users
Configuration
Web user interface Built-in web user interface for easy browser-based configuration (HTTP, HTTPS)
Management
Management protocols Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour
Remote management Yes
Event logging Local, remote syslog, email alerts
Network diagnostics Logging and packet capture
Web firmware upgrade Firmware upgradable through web browser, imported or exported configuration file
Dynamic Host Configuration Protocol (DHCP) DHCP client
IPv6 host Yes
HTTP redirect Yes
Wireless
Frequency Dual bands (2.4 and 5 GHz)
Radio technologies
  • 802.11b : Direct-Sequence Spread-Spectrum (DSSS)
  • 802.11a/g/n/ac : Orthogonal Frequency Division Multiplexing (OFDM)
Modulation types
  • 802.11b : BPSK, QPSK, CCK
  • 802.11a/g/n/ac : BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
WLAN
  • 802.11ac/n
  • 2×2 Multiple-Input Multiple-Output (MIMO) with 2 spatial streams at 5 GHz
  • 2×2 MIMO with 2 spatial streams at 2.4 GHz
  • 20-, 40-, and 80-Mhz channels for 802.11ac
  • 20 and 40 MHz for 802.11n
  • PHY data rate up to 867Mbps
Data rates supported
  • 802.11a/b/g : 54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2, and 1 Mbps
  • 802.11n : 6.5 to 300 Mbps
  • 20-MHz bandwidth : MCS 0-15 for supported data rates
  • 40-MHz bandwidth : MCS 0-15 for supported data rates
  • 802.11ac : 6.5 to 867 Mbps
  • 20-MHz bandwidth : MCS 0-9 for supported data rates
  • 40-MHz bandwidth : MCS 0-9 for supported data rates
  • 80-MHz bandwidth : MCS 0-9 for supported data rates
Frequency band and operating channels A/C Regulatory Domain :

  • 2.412 to 2.462 GHz; 11 channels
  • 5.180 to 5.240 GHz; 4 channels
  • 5.745 to 5.825 GHz; 5 channels

E/J Regulatory Domain:

  • 2.412 to 2.472 GHz; 13 channels
  • 5.180 to 5.240 GHz; 4 channels
K Regulatory Domain :

  • 2.412 to 2.472 GHz; 13 channels
  • 5.180 to 5.240 GHz; 4 channels
  • 5.745 to 5.805 GHz; 4 channels
Non-overlapping channels 2.4 GHz

  • 802.11b/g
    • 20 MHz : 3
  • 802.11n
    • 20 MHz : 3
5 GHz

  • 802.11a
    • 20 MHz : 9
  • 802.11n
    • 20 MHz : 9
    • 40 MHz : 4
  • 802.11ac
    • 20 MHz : 9
    • 40 MHz : 4
    • 80 MHz : 2
Wireless isolation Wireless isolation between clients
External antennas None
Internal antennas Internal Fixed Planar Inverted-F Antenna (PIFA)
Antenna gain In dBi
  • Maximum antenna gain of 4.02 dBi on 2.4 GHz
  • Maximum antenna gain of 5.63 dBi on 5 GHz
Wireless Distribution System (WDS) Yes
Fast roaming Yes
Multiple SSIDs 8
Wireless VLAN map Yes
WLAN security Yes
Wi-Fi Multimedia (WMM) Yes, with unscheduled automatic power save
Operating Modes
Access point Access Point mode, WDS Bridging, Workgroup Bridge mode
Environmental
Power options
  • IEEE 802.3af Ethernet switch
  • Cisco Power Injector: SB-PWR-INJ2-xx
  • AC adapter included, 12V/1A
  • POE peak power : 6.5W
Operating temperature 0° to 40°C (32° to 104°F)
Storage temperature -20° to 70°C (-4° to 158°F)
Operating humidity 10% to 85% noncondensing
Storage humidity 5% to 90% noncondensing
System memory
  • 256 MB RAM
  • 128 MB flash
Package Contents
  • WAP125 Wireless-AC/N Dual Band Desktop Access Point
  • Power adapter 12V/1A
  • Quick-start guide
  • Ethernet network cable
Minimum Requirements
  • Switch/router with PoE support
  • PoE injector, or AC power adapter
  • Web-based configuration : Web browser
