Cisco WAP551 Kenya



Cisco WAP551 Kenya

Cisco WAP551 Kenya deliver business-class, high-capacity wireless connectivity and guest access that is highly secure and reliable. Cisco WAP551 Kenya Access Point, features Wireless-N Single Radio Selectable Band Access Points for small business.

Description

Cisco WAP551 Access Point Kenya

Cisco WAP551 Kenya deliver business-class, high-capacity wireless connectivity and guest access that is highly secure and reliable. Cisco WAP551 Kenya features Wireless-N Single Radio Selectable Band Access Points for small business offer high performance with a single radio selectable band (2.4 or 5.0 GHz). Single Radio 450Mbps Access Point with PoE (ETSI) 802.11n. Experience superior performance and coverage for mobile devices and bandwidth-heavy applications for your small business with this Cisco WiFi Kenya. The simple, controller-less management of Cisco WAP551 wireless access points uses optimized SmartSignal Antenna technology. The Cisco WiFi Kenya also includes Single Point Setup. This controller-less technology simplifies the deployment and management of multiple access points, without requiring additional hardware. The WAP551 also includes Single Point Setup. This controller-less technology simplifies the deployment and management of multiple access points, without requiring additional hardware.

Features

  • Simple installation and intuitive web-based configuration and wizard for deployment and setup in minutes
  • Support for Power over Ethernet (PoE) for easy installation without expensive additional wiring
  • Sleek design with 5 internal antennas and a versatile mounting kit for easy installation on a ceiling or wall
  • Workgroup Bridge mode to help you expand your network by wirelessly connecting to a second Ethernet network
  • Intelligent quality of serve (QoS) that prioritizes network traffic to help keep critical network applications running at top performance
  • Power-saving sleep mode and port control features to help increase energy efficiency
  • IPv6 support to help you deploy future networking applications and operating systems without costly upgrades
  • Single-radio, selectable band support of up to 450 Mbps for optimal capacity and coverage
  • Gigabit Ethernet LAN interface for high-speed uplink to the wired network
  • Comprehensive security with rogue access point detection to help protect sensitive business information
  • Captive portal support for highly secure, customized guest access with multiple rights and roles
  • SmartSignal Antenna to increase wireless coverage by automatically optimizing the antenna pattern
  • Simple installation and intuitive web-based configuration and wizard for deployment and setup in minutes
  • Support for Power over Ethernet (PoE) for easy installation without expensive additional wiring
  • Sleek design with 5 internal antennas and a versatile mounting kit for easy installation on a ceiling or wall
  • Workgroup Bridge mode to help you expand your network by wirelessly connecting to a second Ethernet network

Specifications

Standards IEEE 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460)
Ports LAN Gigabit Ethernet auto sensing
Cabling type Category 5e or better
Antennas Internal antennas optimized for installation on a wall or ceiling
LED indicators Power, WLAN, LAN
Operating system Linux
Physical Interfaces
Ports 10/100/1000 Ethernet, with support for 802.3af PoE
Buttons Reset button
Lock slot Slot for Kensington lock
LEDs Power, Wireless, Ethernet
Physical Specifications
Physical dimensions (W x D x H) 9.05 x 9.05 x .98 in. (230 x 230 x 25 mm)
Weight WAP561 : 1.51 lb or 685 g; WAP551 : 1.41 lb or 640g
Network Capabilities
VLAN support Yes
Number of VLANs 1 management VLAN plus 16 VLANs for SSIDs
802.1X supplicant Yes
SSID-to-VLAN mapping Yes
Auto channel selection Yes
Spanning tree Yes
Load balancing Yes
IPv6 Yes

IPv6 host support

IPv6 RADIUS, syslog, Network Time Protocol (NTP), etc.

Layer 2 802.1Q-based VLANS, 16 active VLANS plus 1 management VLAN
Security
WPA/WPA2 Yes, including Enterprise authentication
Access control Yes, management access control list (ACL) plus MAC ACL
Secure management HTTPS
Wi-Fi Protected Setup (WPS) Yes (soft WPS, no hardware push button)
SSID broadcast Yes
Rogue access point detection Yes
Mounting and Physical Security
Multiple mounting options Mounting bracket included for easy ceiling or wall mounting
Physical security lock Kensington lock slot
Quality of Service
Quality of service (QoS) Wi-Fi Multimedia and Traffic Specification (WMM TSPEC)
Performance
Wireless throughput Up to 450 Mbps data rate (real-world throughput will vary)
Recommended user support Up to 64 connective users, 30 active users per radio
Multiple-Access Point Management
Single Point Setup Yes
Number of access points per cluster 16
Active clients per cluster 480
Configuration
Web user interface Built-in web user interface for easy browser-based configuration (HTTP/HTTPS)
Management
Management protocols Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour
Remote management Yes
Event logging Local, remote syslog, email alerts
Network diagnostics Logging and packet capture
Web firmware upgrade Firmware upgradable through web browser, imported/exported configuration file
Dynamic Host Configuration Protocol (DHCP) DHCP client
IPv6 host Yes
HTTP redirect Yes
Wireless
Frequency
  • WAP551 : Selectable radio band (2.4 or 5 GHz)
  • WAP561 : Dual concurrent radios (2.4 and 5 GHz)
Radio and modulation type Single radio (WAP551) or dual radio (WAP561), orthogonal frequency division multiplexing (OFDM)
WLAN
  • 802.11b/g/n
    • 3×3 multiple-input multiple-output (MIMO) with 3 spatial streams
    • 20 and 40 MHz channels
    • PHY data rate up to 450 Mbps
  • 802.11 dynamic frequency selection (DSF), EU version only
Data rates supported
  • 802.11a/b/g : 54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2, and 1 Mbps
  • 802.11n :
    • 20-MHz bandwidth : MCS 0-15 for supported data rates
    • 40-MHz bandwidth : MCS 0-15 for supported data rates
Frequency band and operating channels 802.11b

2412

2437

2462

802.11g

2412

2437

2462

802.11n 20 MHz (2.4 GHz band)

2412

2437

2462

802.11n 40 MHz (2.4 GHz band)

2422

2437

2452

802.11a

5180

5320

5500

5700

802.11n 20 MHz (5 GHz band)

5180

5320

5500

5700

5825

802.11n 40 MHz (5 GHz band)

5190

5510

5795

Nonoverlapping channels 2.4 GHz

  • 802.11b/g
    • 20 MHz : 3
  • 802.11n
    • 20 MHz : 3

5 GHz

  • 802.11a
    • 20 MHz : 24
  • 802.11n
    • 20 MHz : 24
    • 40 MHz : 11
Wireless isolation Wireless isolation between clients
External antennas None
Internal antennas 5 internal dipole antennas for the WAP551 and 10 antennas for the WAP561
Antenna gain in dBi 5 dBi each antenna
Receiver sensitivity 2.4 GHz

  • 802.11b/g
    • 1 Mbps : –91 dBm
    • 11 Mbps : –85 dBm
    • 6 Mbps : –86 dBm
    • 54 Mbps : –69 dBm
  • 802.11n/20 MHz
    • MCS0 : –86 dBm
    • MCS7 : –70 dBm
    • MCS8 : –85 dBm
    • MCS15 : –68 dBm
  • 802.11n/40 MHz
    • MCS0 : –84 dBm
    • MCS7 : –66 dBm
    • MCS8 : –83 dBm
    • MCS15 : –65 dB

5 GHz

  • 802.11a
    • 6 Mbps : –82 dBm
    • 54 Mbps : –67 dBm
  • 802.11n/20 MHz
    • MCS0 : –83 dBm
    • MCS7 : –68 dBm
    • MCS8 : –82 dBm
    • MCS15 : –66 dBm
  • 802.11n/40 MHz
    • MCS0 : –82 dBm
    • MCS7 : –64 dBm
    • MCS8 : –81 dBm
    • MCS15 : –62 dBm
Wireless distribution system (WDS) Yes
Fast roaming Yes
Multiple SSIDs WAP551: 16

WAP561: 16 x 2

Wireless VLAN map Yes
WLAN security Yes
Wi-Fi Multimedia (WMM) Yes, with unscheduled automatic power save
Operating Modes
Access point Access Point mode, WDS Bridging, Workgroup Bridge mode
Environmental
Power options
  • IEEE 802.3af Ethernet switch
  • Cisco SB-PWR-INJ2-xx
  • POE power :
  • Peak power :
  • WAP551 : 7.872W
  • WAP561 : 11.1W
Operating temperature 0° to 40°C (32° to 104°F)
Storage temperature –20° to 70°C (–4° to 158°F)
Operating humidity 10% to 85% noncondensing
Storage humidity 5% to 90% noncondensing
System memory
  • 64 MB RAM
  • 32 MB flash
Package Contents
  • Cisco WAP551 or WAP561 Wireless-N access point
  • Ceiling/wall mounting kit
  • User guide on CD-ROM
  • Ethernet network cable
