Fanvil A10 Kenya



Fanvil A10 Kenya

The Fanvil A10 Kenya SIP mini intercoms are designed for indoor security, intercom, and broadcasting needs, featuring a sleek design and various user-friendly features.

Description

Fanvil A10 SIP Intercom Kenya

The Fanvil A10 Kenya SIP mini intercoms are designed for indoor security, intercom, and broadcasting needs, featuring a sleek design and various user-friendly features. With 2 SIP accounts, 3 detachable buttons, and PoE power supply, they offer seamless communication.

The A10 series boasts HD audio, IP54 waterproof and dustproof rating, and integrated 2.4G & 5G Wi-Fi (in A10W/A10W-E models) for superior communication quality. It supports wall mount and standard 86 box embedded installations, catering to diverse indoor scenarios.The Fanvil A10 Kenya intercoms enhance security and convenience in residential complexes, offices, and commercial spaces, meeting modern communication demands effectively.

Highlights

  • Features 2 SIP accounts and 3 detachable function buttons
  • Built-in 2.4G & 5G Wi-Fi (A10W/A10W-E)
  • IP54 waterproof and dustproof
  • Support HD audio with codec G.722 and Opus
  • Built-in 2W speaker and Acoustic Echo Canceller (AEC)
  • Built-in 1 short circuit input/output interface
  • Support PoE power supply
  • Support standard 86 box embedded (A10-E/A10W-E) and wall mountable(A10/A10W) installation

Features

Generic

  • 2 SIP Lines
  • Auto answer
  • HD Voice
  • PoE Enabled
  • Built-in 2.4G & 5G Wi-Fi(A10W/A10W-E)
  • Intercom function
  • External Power Supply (Optional)

Intercom Function

  • Support customized DSS keys
  • Network Time Synchronization
  • Built-in Wi-Fi (A10W/A10W-E)
    • 4G, 802.11 b/g/n
    • 5G, 11 a/n
  • Action URL / Active URL

Audio

  • Narrowband Codec : 711a/u, G.729AB, G.723.1, G.726, iLBC
  • Wideband Codec : 722, Opus
  • Duplex intercom with Acoustic Echo Canceller (AEC)
  • Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE)
  • Packet Loss Concealment (PLC)
  • Dynamic Adaptive Jitter Buffer
  • DTMF : In-band, Out-of-Band – DTMF-Relay (RFC2833) / SIP INFO

Networking

  • Physical : 10/100 Mbps Ethernet
  • Wi-Fi : 4G&5G (A10W/A10W-E)
  • IP Mode : IPv4/IPv6/IPv4&IPv6
  • IP Configuration : Static / DHCP / PPPoE
  • Wi-Fi Encryption : WPA /WPA2-PSK /802.X EAP
  • VPN : L2TP / OpenVPN
  • VLAN
  • LLDP
  • QoS

Protocols

  • 0 over UDP/TCP/TLS
  • RTP/RTCP/SRTP
  • STUN
  • DHCP
  • IPv6
  • LLDP
  • PPPoE
  • L2TP
  • OpenVPN
  • SNTP
  • FTP/TFTP
  • HTTP/HTTPS
  • TR-069

Physical Specifications

  • A10 Series : 3 DSS button;
  • Status indicator light :  Fast flashing red (registration failed、network anomaly)、Slow flashing green(call)
  • 1 RJ45 port
  • 1 short circuit input interface
  • 1 relay : NC/NO Contacts, Max DC30V/1A, AC125V/0.5A
  • Power : DC12V/1A or POE
  • Power Consumption (Adapter):
    • 94W~1.98W (A10/A10-E)
    • 42W~2.35W (A10W/A10W-E)
  • Power Consumption (PoE):
    • 48W~2.37W (A10/A10-E)
    • 99W~3.05W (A10W/A10W-E)
  • Housing material : ABS
  • Installation : Indoor installation
    • Standard 86 Box Embedded(A10-E/A10W-E)
    • Wall Mountable(A10/A10W)
  • Color : Gunmetal
  • working temperature : -10 ~50 °C
  • Storage temperature : -20 ~ 50 °C
  • Relative humidity : 10% – 90%
  • Qty/CTN:20 PCS
  • W/CTN : 3.41kg
  • W/CTN : 3.6kg
  • Equipment Dimension :
    • 56 x 87.56 x 30mm (Wall Mountable)
    • 56 x 87.56 x 21.5mm ( 86 Box Embedded)
  • Packing Dimension : 95x106x40mm
  • Outer CTN Dimension : 224x220x210mm(20 PCS)
