Fanvil i23 SIP Audio Door Phone Nairobi

The Fanvil i23 SIP audio door Phone in Nairobi combines IP technology with industrial design, creating a high-quality door entry system perfect for a number of different applications. The design of Fanvil i23 Sip Door phone  is based on experience and knowledge of Fanvil IP phone development. The Fanvil i23 is using standard IP/RTP/SRTP protocol for voice transmission and enjoy the benefits of full range of compatibility. The i23 by Fanvil Kenya has a variety of enterprise‐level features and is compatible with tons of major platforms, such as Asterisk, Broadsoft and Elastix etc.

The Fanvil i23 SIP audio door Phone  is made of the high strength aluminum alloy with Cast aluminum bottom and has non‐removable hexagon screw to keep the surface shell from being removed. This structure can successfully protect the Fanvil i23 from raining, water spraying, dust and decrease man‐made damage. Its power resistant level is up to rated at Ik10 standard. It is also water and dust‐proof level is up to IP65.

The Fanvil i23  accepts the advanced DSP noise reduction algorithms and procedures of omnidirectional sound pickup. During calls, i23 SIP Door Phone Kenya can effectively reduce the background noise. At the same time, it also can optimize the distance of pickups, which promises the high voice quality in any case and delivers good experience for users.

Fanvil i23 SIP Audio Door Phone Features:

• HD Voice with G.722 encoding
• Anti-tamper alarm
• Advanced protection with IP65 and IK10
• Noise reduction
• 2 SIP Lines
• PoE enabled
• Full-duplex speakerphone (HF)
• Numeric keypad (dial pad or password input)
• Intelligent DSS keys (speed dial, intercom, etc)
• Integrated noise reduction module with dual MICs
• 1 indoor switch interface
• 1 electric lock relay
• 2 short-circuit output relays(optional)
• Anti-tamper switch
• External power supply
• Status indication with icons: door opening, talking, call incoming, network/SIP working
• Access control: call, password, RFID card, indoor switch
• Door phone, intercom, and paging to one device
• Protection level: IP65, IK10
• Wall mounting/ Flush mounting

HD Voice Quality :

Built to support the advanced DSP noise reduction algorithms and systematic procedures of omnidirectional sound pickup, the Fanvil i23 SIP Door Phone Kenya delivers crystal clear conversations. It can effectively minimize background noises which may distract the audibility and fluency of phone calls. It can also optimize the sound pickup range, thus guaranteeing its user a high quality voice which in turn leads to a general amazing communication experience. An embedded 3W speaker and AEC mechanism allows for high – quality hands-free communication.

Water & Dust – Resistant :

The Fanvil i23 SIP audio door Phone Kenya is made of the high strength aluminum alloy with Cast aluminum bottom and has a fixed hexagon screw to keep the surface shell from being removed. This structure can successfully prevent the Fanvil i23 IP Door Phone  from moisture, dust and minimizes any man‐made damage. Its power resistant level is up to Ik10 standard, while  its water and dust‐proof level is up to IP65. It is therefore a highly durable device that can withstand harsh weather conditions such as rain, hence saving you from frequent repair costs due to mechanical damages. It can be used in many different outdoor settings.

Multi – Platform Compatibility :

The Fanvil i23 SIP Door Phone is configured to work perfectly with different various professional office platforms including Huawei, BroadSoft, Asterisk, NEC, ZTE, Elastix, 3CX, Metaswitch, Avaya, and many others.

Easy Configuration and Management :

An easy batch deployment incorporated into the Fanvil Device Management System  enables a user to simply configure and manage the Fanvil i23 SIP Door Phone without wasting much time.

2 SIP Lines :

The Fanvil i23 SIP Door Phone supports 2 SIP accounts, therefore boosting efficiency and enhancing communication in the office. This generally improves the productivity of employees.

Supports Power over Ethernet  (PoE) :

The Fanvil i23 SIP Door Phone is a highly economical device which is built to minimize high power consumption using Power over Ethernet. It is equipped with an adaptive 10/100mbps Gigabit Ethernet port which connects to a power source. For users who do not have PoE equipment, the traditional power adapter should be used. If the device is connected to a PoE switch and power adapter at the same time, the power adapter will be used in priority and will switch to PoE power supply at power failure on the power adapter.

SIP Compliance :

The Server-Initiated Application (SIP) is incorporated for users to plug and play the phone without the need for configurations. Once the phone is connected to the network and powered on, initialization commences automatically, after which the phone is up and ready for use. Furthermore, the Fanvil i23 SIP Door Phone can not only be configured via a user interface, it also accepts SIP NOTIFY messages from SIP proxy servers, which gives it an ability to act as a web server. The Fanvil i23 Door Phone is based on SIP v2 (RFC 3261) and works perfectly with most of the SIP platforms such as Asterisk,3CX,  and BroadSoft  that currently exist in the market.

Wall – Mountable, Simple & Space – Saving :

The Fanvil i23 SIP Door Phone is a wall-mountable device which  combines the advantages of a neat, compact appearance with the most commonly used functions of a communication intercom. It is a good choice for hospitals, hotels and general business functions

Fanvil i23 IP Door Phone Specifications :

Access control function :

Two SIP lines, support SIP 2.0 (RFC3261) and related RFC
PoE Enabled
Full-duplex hands-free (HF)
Default Auto Answer
Open the door operation: DTMF, password, RFID card, switch
Support 200,000 door open records
Support 1000 remote access list
Support 1000 RFID cards
Support electric lock internal or external power supply options
Support customized DSS keys
Network Time Synchronization
Action URL / Active URI remote control

Audio :

Narrowband speech codec: G.711a / u, G.723.1, G.726-32K,
G.729AB
Broadband speech codec: G.722
Full Duplex Echo Cancellation (AEC) – 96ms tail-length
DTMF: In-band, out-of-band DTMF (RFC2833) / SIP Info

Networking/ Protocols :

Support PoE (802.3af)
Primary and secondary DNS servers are supported
Support RTSP
Support SNTP client
VLAN
Support VPN L2TP / openVPN
Support SRTP
Support HTTP / HTTPS web pages
Support QoS: 802.1p / q, DSCP
Support MD5 authentication
Support Web Filter
DHCP / static / PPPoE
Support STUN

Deployment & Maintenance :

Auto-Provisioning via FTP / TFTP / HTTP / HTTPS / DHCP / TR069 / SIP PNP
Web Management Portal
Web-based Packet Dump
Configuration Backup / Restore
Entry Log Export
Access Table Export / Import
Firmware Upgrade
Syslog(include door access logs)

Physical Specifications :

1 DSS button (speed dial button)
5 indicator lights (including hot-key backlight)
Numeric keypad
1 indoor switch
1 relay: MAX DC30V / 1A, AC125V / 0.5A
Active switching output: 12V / 650mA DC
RFID reader: ID (EM4100) standard type, IC(MIFARE ONE)
Microphone: -38dB

Speaker: 4Ω / 3W
WAN port: RJ-45, 10 / 100M adaptive
Power supply: 12V ± 15% / 1A DC or POE
PoE: 802.3af (Class 3 – 6.49 to 12.95W)
Network cable: CAT5 or better
Shell Material: Aluminum Cover and Cast-Aluminum back case
Installation method: Wall-mounting or Flush-mounting
Storage Temperature:-40~70℃
Working Humidity: 10~90%
Protection level: IP65 and IK10
Overall Dimension: 223 x 130 x 74mm (W x H x L)
Gift Box Dimensions: 310 x 175 x 115mm
Outer CTN Dimensions: 370 x 370 x 330mm(6 PCS)
Package Weight:1800g
