Fanvil i51W SIP Indoor Station Kenya
The i51W acts as an interface between you and the SIP door phone or intercom at the residence’s entrance providing a reliable and convenient way to deploy remote access control projects. The i51W can also be connected to alarms and smart security devices for added functionality. It provides a user-friendly interface that adds to the experience with its simple-to-use buttons and elegant design. HD Audio and an H.264 video codec offer a great audio and video experience with clear images and sounds.
The five buttons on the i51W serve the following functions: Call Management, Unlock, Pick Up, Surveillance, Back/Hang Up. The i51w can connect multiple devices such as a door sensor, IP phone, vibration sensor, emergency button, door phone and or a PIR sensor among others. Another perk of the i51W? It features built-in 2.4G Wi-Fi.
Fanvil i51W SIP Indoor Station Kenya Features:
- 4.3-inch color screen
- 5 physical function keys
- Built-in 1.5W speaker with AEC
- Support visual intercom and remote access control
- Real-time monitor of the door phone and cameras
- Built-in 2.4G Wi-Fi
- 8 alarm input interfaces
- 1 pair of RS-485 interfaces
- Wall-mounted and desktop installation methods (with the
external desk stand) - Compatible with major platforms: 3CX, Avaya, Asterisk,
- BroadSoft, Metaswitch, Elastix and etc.
- Elegant Design with 4.3-inch Color Screen
- Fanvil i51W delivers a user-friendly experience with an elegant design and a clear 4.3-inch color screen.
- HD Audio and Video Communication
- Users can communicate with visitors with superb audio and clear video images via Fanvil i51W.
- 5 Easy-to-access Physical Buttons
- Users can easily achieve different functions including surveillance, back/hang up, unlock, pick up, and call management with one press on Fanvil i51W.
- Built-in 2.4G Wi-Fi
- Fanvil i51W supports built-in 2.4G Wi-Fi, and it allows users to choose wireless connection mode for different requirements.
- Rich Interfaces
- Fanvil i51W is flexible and powerful with rich interfaces to connect more security devices.
Fanvil i51WÂ Technical Specifications
General
- 4 SIP Lines
- HD Voice
- PoE
- External Power Supply(Optional)
Display
- 1 x LCD: 4.3-inch 480×272 Colour Screen
Audio
- Wideband ADC/DAC 16KHz sampling
- Narrowband codec: G.711A/U, G.729AB, iLBC
- Wideband codec: G.722, Opus
- Full-duplex hands-free speakerphone with AEC
- Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR)
- Packet Loss Concealment (PLC)
- Dynamic Adaptive Jitter Buffer
- DTMF: In-band, Out-of-Band – DTMF-Relay (RFC2833) / SIP INFO
- VQM voice quality monitoring
Video
- Hardware video decoding: H.264
- Video call resolution: QVGA / CIF / VGA / 4CIF / 720P / 1080P
Network
- 10/100 Mbps Ethernet
- IP Mode:IPv4/IPv6/IPv4&IPv6
- IP Configuration: Static / DHCP / PPPoE
- VPN: L2TP / OpenVPN
- QoS
- RTCP-XR (RFC3611), VQ-RTCPXR(RFC6035)
- WiFi
Protocols
- SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS
- RTP/RTCP/SRTP
- STUN
- DHCP
- IPv6
- PPPoE
- L2TP
- OpenVPN
- SNTP
- FTP/TFTP
- HTTP/HTTPS
- TR-069
Deployment & Management
- Auto-provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069
- Web management portal
- Web-based packet dump
- Configuration export / import
- Firmware upgrade
- Syslog
Physical Specification
- 5 Function keys (Management Center, Monitor, Unlock, Return/Hang up, Answer)
- 10 Pin Cable x1
- 4 Pin Cable x1
- 2 Pin Cable x1
- Wall-mount Bracket x1
- Screws Kit x1
- RJ45 Interface x1
- RS485 Interface x1
- Alarm Input Interface x8
- DC Power Input: 12V/1A
- Power Consumption (PoE): 1.82~5.93 W
- Power Consumption (Adapter): 1.54~4.78 W
- Working Temperature: 0~45℃
- Working Humidity: 10~90%
- Colour: White
- Installation:
–Â Desktop (Need to purchase stand separately)
– Wall-mounted - Device Dimensions: 163x104x26 mm
- Gift Box Dimensions: 179x115x40 mm
- Outer CTN Dimensions: (20 PCS) 380x225x250 mm
