Description

Grandstream GWN7830 Layer 3 Managed Network Switch Kenya

The Grandstream GWN7830 Kenya is a series of Layer 3 aggregation managed switches that allow businesses to create scalable, secure, high-performance, and intelligent networks. These networks are fully manageable and can handle high capacity. The Grandstream GWN7830 Kenya provides advanced VLAN for flexible traffic segmentation, sophisticated QoS for prioritizing network traffic, IGMP/MLD Snooping for optimized network performance, and strong security features to protect against potential attacks. Users can manage the switches through the local Web user interface and CLI. Additionally, the Grandstream GWN7830 Kenya is compatible with GWN.Cloud and GWN Manager, Grandstream’s network management platform for both cloud and on-premise solutions. With its comprehensive end-to-end quality of service, customizable security settings, and ability to support high network capacity, the Grandstream GWN7830 Kenya is an ideal choice for medium-to-large enterprises.

Grandstream GWN7830 Core Features

• 6 x SFP
• 4 x SFP+
• 2 x GigE
• Supports deployment in IPv6 and IPv4 networks.
• ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
• Embedded controller to manage switch; GWN. Cloud and GWN Manager, Grandstream’s cloud and on-premise network management platform
• Built-in QoS allows for prioritization of network traffic

Additional Information

Technical Specifications

GENERAL INFO :

• Model :  GWN7830
• Box Contents :
  • 1x GWN7830 Switch
  • 1x 1.2m(10A) AC Cable
  • 1x 25cm Ground Cable
  • 4x Rubber Footpads
  • 1x Power Cord Anti-Trip
  • 2x Extended Rack-Mounting Kits
  • 8x Screws(KM 3*6)
  • 1x Quick Installation Guide

NETWORK PROTOCOL :

• IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE
  802.1p, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x
• Gigabit Ethernet Ports :  2
• Gigabit SFP Ports :  6
• Gigabit SFP+ Ports :  4
  • Note :  Support DAC Cable and must be ≤ 5m
• Maximum no. of Supported Modules :
  • SM-1G :  6
  • MM-1G :  6
  • RJ45-1G :  3
  • SM-10G :  4
  • MM-10G :  4
  • RJ45-10G :  2
  • Note :  RJ45-1G, RJ45-10G modules must be interval inserted
• Console :  1
• Integrated Power Supply :  30W
• Auxiliary Ports :  1x Reset Pinhole
• Forwarding Mode :  Store-and-forward
• Total non-blocking throughput :  48Gbps
• Switching Capability :  96Gbps
• Forwarding Rate :  71.424Mpps
• Packet Buffer :  12Mb
• Network Latency : <4µs
