Huawei S310-48T4S Kenya



Huawei S310-48T4S Kenya

The Huawei S310-48T4S Kenya fixed Ethernet switches are expertly designed to blend access and transmission functionalities seamlessly, ensuring reliable access, aggregation, and high-quality service transmission for enterprise networks.

Description

Huawei S310-48T4S Network Switch Kenya

The Huawei S310-48T4S Kenya fixed Ethernet switches are expertly designed to blend access and transmission functionalities seamlessly, ensuring reliable access, aggregation, and high-quality service transmission for enterprise networks. These switches are built on a robust and unified hardware platform, featuring essential components like the chassis, power module, fan module, and Switch Control Unit (SCU). As unmanaged switches, the Huawei S310-48T4S Kenya models are intentionally designed without web-based management interfaces or SNMP-based management, emphasizing simplicity, ease of use, and straightforward deployment for users who prefer minimal configuration and maintenance.

These switches offer a hassle-free experience for network administrators, making them an excellent choice for environments where ease of use and reliability are paramount. They are specifically designed to support dependable service transmission, access, and aggregation, allowing enterprises to maintain efficient network operations without the need for complex management tools. This simplicity makes them ideal for businesses that prioritize ease of use, reliability, and efficiency in their network infrastructure.

The unified hardware platform and high-quality components ensure the durability and longevity of these switches, reducing the frequency of replacements or upgrades. The easy deployment and minimal maintenance requirements save time and resources for IT departments, enabling them to focus on other critical tasks. As a result, the Huawei S310-48T4S Kenya switches are an ideal solution for businesses seeking a straightforward, reliable, and efficient network infrastructure.

Technical Specifications

Description S310-48T4S (48*10/100/1000BASE-T ports, 4*GE SFP ports, AC power)
Part Number 98012203
Model S310-48T4S
First supported version V600R022C10
Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.)

Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)

Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.)
Chassis height [U] 1 U
Chassis material Metal
Weight without packaging [kg(lb)] 2.71 kg (5.97 lb)
Weight with packaging [kg(lb)] 3.59 kg (7.91 lb)
Typical power consumption [W] 44.9 W
Typical heat dissipation [BTU/hour] 153.2 BTU/hour
Maximum power consumption [W] 52.05 W
Maximum heat dissipation [BTU/hour] 177.6 BTU/hour
Static power consumption [W] 27.55 W
MTBF [years] 40.61 years
MTTR [hours] 2 hours
Availability > 0.99999
Noise at normal temperature (acoustic power) [dB(A)] 46.6 dB(A)
Noise at normal temperature (acoustic pressure) [dB(A)] 34.6 dB(A)
Number of card slots 0
Number of power slots 0
Number of fans modules 1
Switching capacity To obtain data of this specification item, see the corresponding datasheet or contact the product sales personnel.
Packet forwarding rate To obtain data of this specification item, see the corresponding datasheet or contact the product sales personnel.
Uplink ports 4 x GE SFP ports
Downlink ports 48 x 10/100/1000BASE-T ports
Redundant power supply Not supported
Long-term operating temperature [°C(°F)] -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.)
Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

Devices cannot start when the temperature is lower than 0°C (32°F).

The operating temperature ranges from –5°C (23°F) to +45°C (113°F) when optical modules with transmission distances greater than or equal to 60 km are used.

The device does not support dying gasp when the ambient temperature is higher than 40°C (104°F).

Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing)
Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.)
Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.)
Power supply mode AC built-in
Rated input voltage [V] AC input: 100–240 V AC; 50/60 Hz
Input voltage range [V] AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz
Maximum input current [A] 1.6 A
Memory 2 GB
Flash memory Physical space: 1 GB
Console port RJ45
Eth Management port Not supported
USB Not supported
RTC Not supported
RPS input Not supported
Service port surge protection [kV] Common mode: ±7 kV
Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV
Ingress protection level (dustproof/waterproof) IP20
Types of fans Built-in
Heat dissipation mode Air cooling for heat dissipation, intelligent fan speed adjustment
Airflow direction Air intake from left and air exhaust from right
PoE Not supported
Certification
  • EMC certification
  • Safety certification
  • Manufacturing certification
