Description
Huawei S380-S8P2T Multi-Service Gateway Kenya
The Huawei S380-S8P2T Kenya Multi-Service Gateways are state-of-the-art devices that seamlessly integrate routing, switching, and wireless access control (WAC) functionalities into a single, versatile unit. These advanced gateways come in various configurations, designed to meet a wide range of network requirements. They feature either 4 or 8 downlink GE electrical ports, with both PoE (Power over Ethernet) and non-PoE options available, allowing users to select the setup that best fits their specific needs. Additionally, some models are equipped with GE uplink ports, enhancing network flexibility and performance.
Engineered with user convenience in mind, the Huawei S380-S8P2T Kenya Multi-Service Gateways support flexible Ethernet networking, significantly simplifying installation and deployment. This user-friendly design makes them an excellent choice for a broad spectrum of indoor coverage applications. These gateways are particularly beneficial for small and medium-sized enterprises (SMEs), including small office/home office (SOHO) environments, budget-conscious hotels, manufacturing facilities, primary and secondary educational institutions, and building security systems. Their remarkable versatility and adaptability ensure that the Huawei S380-S8P2T Kenya can effectively meet the diverse networking needs of various business sectors, delivering efficient and reliable performance across numerous applications.
Moreover, the Huawei S380-S8P2T gateways are designed to be highly scalable, ensuring that as businesses grow and their networking demands increase, the gateways can be easily upgraded and expanded to accommodate these changes. The integration of advanced security features provides robust protection against potential threats, ensuring the integrity and confidentiality of the network. The combination of these features makes the Huawei S380-S8P2T Kenya Multi-Service Gateways an optimal solution for businesses seeking a reliable, high-performance networking device that can adapt to their evolving needs.
Technical Specifications
| Description | S380-S8P2T, 2*GE WAN, 8*GE LAN(PoE+, 124W) |
| Part Number | 98012180 |
| Model | S380-S8P2T |
| First supported version | V600R022C10 |
| Dimensions without packaging (H x W x D) [mm(in.)] | Basic dimensions (excluding the parts protruding from the body): 35.0 mm x 210.0 mm x 130.0 mm (1.38 in. x 8.27 in. x 5.12 in.)
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 35.0 mm x 210.0 mm x 136.3 mm (1.38 in. x 8.27 in. x 5.37 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] | 150.0 mm x 275.0 mm x 200.0 mm (5.91 in. x 10.83 in. x 7.87 in.) |
| Chassis height [U] | 0.8 U |
| Chassis material | Metal |
| Weight without packaging [kg(lb)] | 1.5 kg (3.31 lb) |
| Weight with packaging [kg(lb)] | 1.8 kg(lb) |
| Typical power consumption [W] | 12.4 W |
| Typical heat dissipation [BTU/hour] | 42.3 BTU/hour |
| Maximum power consumption [W] | 145.8 W (PoE: 124 W) |
| Maximum heat dissipation [BTU/hour] | 497.5 BTU/hour |
| Static power consumption | 7.53 |
| MTBF [years] | 65.36 years |
| MTTR [hours] | 2 hours |
| Availability | > 0.99999 |
| Noise at normal temperature (acoustic power) [dB(A)] | Noise-free (no fans), < 30 |
| Noise at normal temperature (acoustic pressure) [dB(A)] | Noise-free (no fans), < 20 |
| Number of card slots | 0 |
| Number of power slots | 0 |
| Number of fans modules | 0 |
| Switching capacity | To obtain data of this specification item, see the corresponding datasheet or contact the product sales personnel. |
| Packet forwarding rate | To obtain data of this specification item, see the corresponding datasheet or contact the product sales personnel. |
| WAN ports | 2 x GE WAN |
| LAN ports | 8 x GE LAN (124 W PoE+) |
| Redundant power supply | Not supported |
| Long-term operating temperature [°C(°F)] | 0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) |
| Restriction on the operating temperature variation rate [°C(°F)] | When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). |
| Storage temperature [°C(°F)] | –40°C to +70°C (–40°F to +158°F) |
| Long-term operating relative humidity [RH] | 5% RH to 95% RH (non-condensing) |
| Long-term operating altitude [m(ft.)] | 0–5000 m (0–16404 ft.) |
| Storage altitude [m(ft.)] | 0-5000 m (0-16404 ft.) |
| Power supply mode | Power adapter |
| Rated input voltage [V] | Power adapter input: 100–240 V AC; 50/60 Hz
Power adapter output: 56 V DC |
| Input voltage range [V] | Power adapter input: 90–290 V AC; 47–63 Hz |
| Maximum input current [A] | 2.68 A |
| Memory | DDR4: 512 MB |
| Flash memory | NAND Flash: 512 MB |
| Console port | Not supported |
| Eth Management port | LAN port |
| USB | Not supported |
| RTC | Not supported |
| RPS input | Not supported |
| Service port surge protection [kV] | Common mode: ±4 kV |
| Power supply surge protection [kV] | Power adapter: ±6 kV in differential mode and ±6 kV in common mode |
| Ingress protection level (dustproof/waterproof) | IP20 |
| Types of fans | None |
| Heat dissipation mode | Natural heat dissipation |
| Airflow direction | – |
| PoE | Supported |
| Certification |
|
