Tplink TL-SG2008 Kenya

Description

Tplink TL-SG2008 Smart Switch Kenya

Tplink TL-SG2008 Kenya Smart Switch expands your office or business network capacity to handle a multitude of applications. With its 16 Gb/s switching capacity and 11.9 Mpps forwarding rate, Tplink TL-SG2008 switch provides smooth data transfers that are optimized for voice and video applications. This managed switch features eight Gigabit Ethernet ports, one of which supports PoE in as an alternative to using the included AC power adapter when connected to compatible equipment. Your data is protected by a host of security features, including an Access Control List (ACL) and VLAN support. Use the Omada Software Defined Networking platform to manage your connected network devices and manage them remotely with the Omada app.

Features

Full Gigabit Ports : 8× gigabit RJ45 ports provide high-speed connections.
Integrated into Omada SDN : Zero-Touch Provisioning*, Centralized Cloud Management, and Intelligent Monitoring.
Centralized Management : Cloud access and Omada app for ultra-convenience and easy management.
Robust Security Strategies : 802.1Q VLAN, ACL, Port Security, Storm Control, and more.
Optimize Voice and Video Applications : L2/L3/L4 QoS and IGMP snooping.
Versatile Management : WEB/CLI managed modes, SNMP, and RMON bring abundant management features.

Software Defined Networking (SDN) with Cloud Access

Omada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.

Centralized Management

The Omada Software Defined Networking (SDN) platform integrates access points, switches, gateways, and other network devices to provide high efficiency, security, and reliability.

Omada App

Configure, manage, and monitor your network devices from almost anywhere in the world using your smartphone or tablet.

Access Control List

Tplink TL-SG2008 Kenya packs security features that allow or deny connected devices access to data with user-defined network rules.

Optimized Traffic

Configure the switch to prioritize voice and video traffic to help ensure clear calls and smooth media streaming.

VLAN Support

Group devices using VLAN to help improve network security and reduce data congestion.

Security Features

Tplink TL-SG2008 Kenya protect your network from attacks and intrusions with IP-MAC-Port Binding, Access Control List, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1x, Radius Authentication, and more.

Quiet Operation

The metal chassis allows the switch to operate silently while dissipating heat.

Specifications

HARDWARE FEATURES
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Interface	8 10/100/1000Mbps RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX)
Network Media	10BASE-T : UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000Base-T : UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity	Fanless
Power Supply	12 VDC/1 A External Adapter or Obtain Power from PoE Source
Power Consumption	6.4 W (220 V/50 Hz)
Dimensions ( W x D x H )	8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm)
PERFORMANCE
Bandwidth/Backplane	16 Gbps
Packet Forwarding Rate	11.9 Mpps
MAC Address Table	8K
Packet Buffer Memory	4.1 Mbit
Jumbo Frame	9 KB
SOFTWARE FEATURES
Quality of Service	802.1p CoS/DSCP priority 8 priority queues Priority Schedule Mode SP (Strict Priority) WRR (Weighted Round Robin) Queue Weight Config Bandwidth Control Port/Flow based Rating Limit Smoother Performance Storm Control Multiple Control Modes(kbps/ratio) Broadcast/Multicast/Unknown-Unicast Control
L2 and L2+ Features	16 IP Interfaces Support IPv4/IPv6 Interface Static Routing 32 IPv4/IPv6 Static Routes DHCP Server DHCP Relay DHCP Interface Relay DHCP VLAN Relay DHCP L2 Relay Static ARP Proxy ARP Gratuitous ARP Link Aggregation Static link aggregation 802.3ad LACP Up to 8 aggregation groups and up to 8 ports per group Spanning Tree Protocol 802.1D STP 802.1w RSTP 802.1s MSTP STP Security : TC Protect, BPDU Filter/Protect, Root Protect Loopback Detection Flow Control 802.3x Flow Control Mirroring Port Mirroring CPU Mirroring One-to-One Many-to-One Flow-Based Ingress/Egress/Both Device Link Detect Protocol (DLDP) 802.1ab LLDP/ LLDP-MED
VLAN	VLAN Group Max. 4K VLAN Groups 802.1Q tag VLAN MAC VLAN : 12 Entries Protocol VLAN GVRP Voice VLAN
Access Control List	Support up to 230 entries Time-Range Time Slice Week Time-Range Absolute Time-Range Holiday Time-based ACL MAC ACL Source MAC Destination MAC VLAN ID User Priority Ether Type IP ACL Source IP Destination IP IP Protocol TCP Flag TCP/UDP Source Port TCP/UDP Destination Port DSCP/IP TOS IPv6 ACL Combined ACL Rule Operation Permit/Deny Policy Action Mirror Rate Limit Redirect QoS Remark ACL Rules Binding Port Binding VLAN Binding Actions for flows Mirror (to supported interface) Redirect (to supported interface) Rate Limit QoS Remark
Security	AAA 802.1X Port based authentication MAC (Host) based authentication Authentication Method includes PAP/EAP-MD5 MAB Guest VLAN Support Radius authentication and accountability IP/IPv6-MAC Binding 512 Binding Entries DHCP Snooping DHCPv6 Snooping ARP Inspection ND Detection IP Source Guard 253 Entries Source IP+Source MAC IPv6 Source Guard 183 Entries Source IPv6 Address+Source MAC DoS Defend Static/Dynamic/Permanent Port Security Up to 64 MAC addresses per port Broadcast/Multicast/Unicast Storm Control kbps/ratio control mode Port Isolation Secure web management through HTTPS with SSLv3/TLS 1.2 Secure Command Line Interface (CLI) management with SSHv1/SSHv2 IP/Port/MAC based access control
Management	Web-based GUI Command Line Interface (CLI) through telnet SNMPv1/v2c/v3 SNMP Trap/Inform RMON (1,2,3,9 groups) SDM Template DHCP/BOOTP Client Dual Image, Dual Configuration CPU Monitoring Cable Diagnostics EEE SNTP System Log
Advanced Features	Automatic Device Discovery Batch Configuration Batch Firmware Upgrading Intelligent Network Monitoring Abnormal Event Warnings Unified Configuration Reboot Schedule
MANAGEMENT
Omada App	Yes, through Omada Cloud-Based Controller (Not Supported by TL-SG2428P v2) OC300 OC200 Omada Software Controller
Centralized Management	Omada Cloud-Based Controller (Not Supported by TL-SG2428P v2) Omada Hardware Controller OC300 Omada Hardware Controller OC200 Omada Software Controller
Cloud Access	Yes, through Omada Cloud-Based Controller (Not Supported by TL-SG2428P v2) OC300 OC200 Omada Software Controller
Zero-Touch Provisioning	Yes. Requiring the use of Omada Cloud-Based Controller (Supported by TL-SG2428P v1, v3 and above, while is not supported by TL-SG2428P v2)
Management Features	Web-based GUI Command Line Interface (CLI) through telnet SNMPv1/v2c/v3 SNMP Trap/Inform RMON (1,2,3,9 groups) SDM Template DHCP/BOOTP Client Dual Image, Dual Configuration CPU Monitoring Cable Diagnostics EEE SNTP System Log
OTHERS
Certification	CE, FCC, RoHS
Package Contents	TL-SG2008 Power Adapter Installation Guide Rubber Feet
System Requirements	Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux.
Environment	Operating Temperature : 0℃~40℃ (32℉~104℉); Storage Temperature : -40℃~70℃ (-40℉~158℉) Operating Humidity : 10%~90% non-condensing Storage Humidity : 5%~90% non-condensing
